FLUKE 110 SERIES ELECTRICIANS DIGITAL MULTIMETERS
114 Electrical Multimeter
The 114 is ideal for electrical
troubleshooting and
straightforward 'go/no-go'
testing in residential/commercial
electrical testing. It has all the
basic functions plus a special
feature to prevent false readings
caused by ghost voltage.
115 for field service testing
An everyday multimeter
for technicians, the 115 is
optimised for electrical and
electronic testing in the
field service, industrial, and
applications where more
than basic functionality (such
as measurement of AC/C
current)simplifies working.
116 Multimeter with
temperature and microamps
The 116 is for heating,
ventilation and air conditioning
(HVAC)engineers. It includes
temperature measurement and
microamp current ranges (with
a resolution of 0.1µA ) to quickly
troubleshoot HVAC problems.
117 Electrician's Multimeter
with Non-Contact Voltage
For electricians working
in commercial and
non-commercial premises
(like hospitals and schools),
the 117 is recommended. It
includes extras like non-contact
voltage detection to help get
the job done faster and safer.
114F 115F 116F 117F
Display backlight
�
�
�
�
Analogue bar graph
�
�
�
�
AutoVolt (AC/DC detection)
�
�
�
VoltAlert (Non-contact voltage detection)
�
Built-in thermometer for HVAC
�
LoZ: low input impedance
�
�
�
Min/Max/Avg
�
�
�
�
Resistance /Continuity
�
�
�
�
Frequency /Capacitance /Diode test
�
�
�
Microamps to test flame sensors
�
Display hold
�
�
�
�
Auto/manual ranging
�
�
�
�
Compact case with removable holster
�
�
�
�
114F
115F
116F
117F
Display
6000 count + 33-seg bar
DC Voltage
600V
0.1mV ±(0.5%+2)
AC Voltage
600V
0.1mV ±(1.0%+3)
DC Current
-
10A
1mA
±(1.0%+3)
10A
1mA
±(1.0%+2)
AC Current
-
10A
0.01mA
±(1.5%+3)
10A
0.01mA
±(1.0%+2)
10A
0.01mA
±(1.5%+3)
Resistance
40MΩ
0.1Ω ±(0.9%+1)
Capacitance
-
10,000µF
1nF ±(1.9%+2)
Frequency
-
50kHz
0.01Hz ±(0.1%+2)
Temperature
-
–40~400°C
0.1°C±(1.0%+10²)
-
Continuity tone
Yes
Diode test
Yes
114F
44482291
115F
44482292
116F
44482294
117F
44482296
CAPACITANCE/RESISTANCE METER
Designed to test resistance & capacitance
˺˺
Diode & Continuity Buzzer
˺˺
Transistor tester
˺˺
Auto power off
Display
1999 (max display)
Resistance
2000MΩ
±(0.8%+1)
Capacitance
20mF
±(0.5%+10)
Continuity tone
Yes
Diode test
Yes
UT601
44488240
HOBBY DIGITAL MULTIMETER
˺˺
Low Cost, ideal for
hobby and DIY users
˺˺
High Safety Design
˺˺
Protective Holster
with Bench Stand
˺˺
Low Battery,
Overrange &
Polarity Indication
˺˺
Size: 138 x 69 x 31mm
˺˺
Weight: 170g
Display
3½ digits (1,999 max)
DC Voltage
600V
±0.5%
AC Voltage
600V
±1.2%
DC Current
10A
±1.0%
Resistance
2M O ±0.8%
Continuity tone
Yes
Diode test
Yes
DM830L
44488098
