INDUSTRIAL TRUE RMS MULTIMETER
New features for maximum productivity—for accurate
voltage and frequency measurements on adjustable
speed motor drives and other electrically noisy equipment
˺˺
Built-in thermometer
˺˺
Large digit display
with bright, two-
level backlight
˺˺
True-RMS AC
voltage and current
for accurate
measurements on
non linear signals
˺˺
Selectable filter for
accurate voltage
and frequency
measurements
on motor drives
˺˺
Peak capture to
record transients
as fast as 250 µs
˺˺
Relative mode to
remove test lead
interference from
lowΩ measurements
˺˺
"Classic" design
with new removable
holster with built-in
test lead and
probe storage
Display
4½ digits (20,000 counts)
DC Voltage
1000V
10µV ±(0.05%+1)
AC Voltage
1000V
1mV ±(0.7%+2)
DC Current
10A
0.01µA ±(0.2%+2)
AC Current
10A
0.1µA ±(1.0%+2)
Resistance
50MΩ
0.1Ω ±(0.2%+1)
Capacitance
9,999µF
0.01nF ±(1.0%+2)
Frequency
200kHz
0.01Hz ±(0.005%+1)
Duty
99.9%
0.1% ±(0.2%/kHz+0.1%)
Temperature
–200~1090°C
Continuity tone
Yes
Diode test
Yes
87-V
44482570
REMOTE DISPLAY TRMS MULTIMETER
Place the removable display where you can see it and then put
the meter where it is convenient for you—no more juggling
of leads and the meter while stretching into a tight spot.
˺˺
True-RMS AC voltage and current for accurate
measurements on non-linear signals
˺˺
Low power wireless technology allows the
display to be carried up to 10 meters (33 ft)
Display
3½ digits (6,000 counts)
DC Voltage
1000V
0.1mV ±(0.25%+2)
AC Voltage
1000V
0.1mV ±(1.0%+3)
DC Current
10A
0.01mA ±(1.0%+3)
AC Current
10A
0.01mA ±(1.5%+3)
Resistance
40MΩ
Capacitance
9,999µF
1nF
Frequency
50kHz
0.01Hz ±(0.1%+2)
Temperature
–40~400°C
Continuity tone
Yes
233F
44482400
FLUKE 170 SERIES DIGITAL MULTIMETERS
175F
177F
179F
˺˺
True RMS
Voltage and
Current
measurements
˺˺
0.09% basic
accuracy
˺˺
Display
backlight
˺˺
Temperature
measurement
Display
6000 count + 33-seg bar
DC Voltage
1000V
0.1mV ±(0.15%+2)
1000V
0.1mV ±(0.09%+2)
AC Voltage
1000V
0.1mV ±(1.0%+3)
DC Current
10A
0.01mA ±(1.0%+3)
AC Current
10A
0.01mA ±(1.5%+3)
Resistance
50MΩ
0.1Ω ±(0.9%+1)
Capacitance
10,000µF
1nF ±(1.2%+2)
Frequency
100kHz
0.01Hz ±(0.1%+1)
Temperature
-
–40~400°C
0.1°C ±(1.0%+10)
Continuity tone
Yes
Diode test
Yes
Other Features
-
˺˺
Display backlight
These meters have the features needed to find most electrical, electro-
mechanical and heating and ventilation problems. They are simple to
use and have significant improvements over Fluke's original 70 Series
like, True-RMS, more measurement functions, conformance to the latest
safety standards, and a much larger display that's easier to view.
˺˺
True RMS voltage and
current measurements
˺˺
0.09% basic accuracy (179, 177)
˺˺
Digital display with
analogue bar graph
˺˺
Manual and automatic ranging
˺˺
Frequency and capacitance
measurements
˺˺
Min /Max /Avg recording
˺˺
Measures twice as fast
as other multimeters
175F
44482517
177F
44482532
179F
44482540
DIAGNOSTIC & LOGGING MULTIMETER
The Fluke 289 true-RMS digital multimeter was
designed for those of you at the top of your field.
The instrument replaces the popular 180 Series,
with all the same features, plus more. This
multimeter performs advanced unattended data
logging, and shows trend data on screen without
having to download to a PC. TrendCapture helps
engineers and technicians track down problems
faster during (for example)preventive and predictive
maintenance. All the features of the 287F plus:
˺˺
Two terminal 50Ω range with
1 mΩ resolution, 10 mA
˺˺
Low Pass filter for accurate voltage
and frequency measurements on
adjustable speed motor drives
˺˺
LoZ Volts. Low impedance
voltage function for
eliminating ghost voltages
˺˺
Saved measurements allow
you to name and recall
measurements made in the field
˺˺
Optical USB PC communication
interface allows for easy PC
download to document logged data
with FVF software (not included).
Display
Graphical (50,000 counts)
DC Voltage
1000V
0.025%
AC Voltage
1000V
0.4%
DC Current
10A
0.05%
AC Current
10A
0.6%
Resistance
500MΩ
0.05%
Capacitance
100mF
1.0%
Frequency
999.99kHz
0.005%
Continuity tone
Yes
Diode test
Yes
289F
44482575
448
