300 STANDARD VICE BASE
Holds all regular
PANAVISE heads and
Circuit Board Holders
˺˺
Accepts all 300
series heads and
the PV Jr. 203
Head or any 5/8"
diameter shaft
˺˺
Patented single
control knob and
exclusive "split-ball"
locks the head
firmly in place
˺˺
Base features
4.3125" (109.5mm)
bolt circle
countersunk
˺˺
Height:
3.75" (95.2mm)
˺˺
Weight:
1.4 lbs. (0.6kg)
PV300
52802001
305 LOW PROFILE VICE BASE
Lowest profile Base
on the market!
˺˺
For working closely
to the bench
surface, accepts
all 300 series and
any 5/8" heads
˺˺
Use with the 304
Low-Profile Head
to create a very
low-profile vice
˺˺
Patented single
control knob and
exclusive "split-
ball" locks Head
firmly in place
˺˺
Base features
4.3125" (109.5mm)
bolt circle
countersunk
˺˺
Height:
2.5" (63.5mm)
˺˺
Weight:
1.3 lbs. (0.6kg)
PV305
52802005
203 SMALL VICE HEAD JAW
Our most popular Vice
Head for arts and
crafts, model making,
electronics and other
small projects! We
have adapted a PV
Jr. Head to fit all 300
series bases. Now you
can add all the popular
features of a PV Jr. to a
larger 300 series base.
˺˺
Fine/coarse adjusting
knob controls
jaw pressure
˺˺
Jaws feature
horizontal grooves
for holding small
tubes, rods, or small
circuit boards
˺˺
Reinforced thermal
composite plastic
˺˺
Jaws are 2"
(50.8mm)tall,
1" (25.4mm)
wide and open to
2.875" (73mm)
˺˺
Height:
3.75" (95.2mm)
˺˺
Weight:
0.4 lbs. (0.2kg)
PV203
52802013
303 STANDARD HEAD JAW
The tough yet gentle nylon jaws have a satin finish
to improve grip. The heavy duty adjusting screw
turns in a brass bushing which is pressure diecast
into the head as are the double steel guide pins.
˺˺
Perfect for hobbies,
electronics and
small home repairs!
˺˺
Select the 300,
305 or 380 Base
and create your
own versatile vice
˺˺
Jaws are 2.5"
(63.5mm)wide,
0.5" (12.6mm)
tall and open to
2.25" (57.1mm)
˺˺
Excellent electrical
insulation -
continuous 93°C,
intermittent heat
up to 149°C
˺˺
Throat depth:
1.375" (34.9mm)
˺˺
Height:
4.25" (108.0mm)
˺˺
Weight:
1.5 lbs. (0.7kg)
PV303
52802016
310 SURFACE PLATE BASE MOUNT
This unique Base Mount features a
precision cast iron flat surface (Blanchard
ground)- ideal for layout work!
˺˺
Compatible with the 201 PV Jr.
Vice and 300 & 305 Bases
˺˺
Square surface:
273.1mm x 273.1mm
˺˺
Includes four
non-marring,
anti-skid pads
˺˺
Height:
1.25" (31.8mm)
˺˺
Weight:
10.0 lbs. (4.5kg)
PV310
52801945
311 BENCH CLAMP BASE MOUNT
Clamps to a table, workbench, ladder, wherever
you need it! Includes four non-marring, anti-
skid neoprene pads for additional anti-slip
characteristics without excessive tightening.
˺˺
Take your vice
anywhere you
need it! Clamps
to anything
up to 4.4375"
(87.3mm)thick
˺˺
Compatible with the
201 PV Jr. Vice and
300 & 305 Bases
˺˺
Finger grip for
added convenience
˺˺
Throat depth from
centre of clamping
screw:
2.3125" (58.7mm)
˺˺
Weight:
2.4 lbs. (1.1kg)
PV311
52801950
312 TRAY BASE MOUNT PLATE
Neatly organizes your small parts and tools!
This cast aluminium Base Mount adds stability
and has six integral parts wells with rounded
and sloped walls for easy parts retrieval.
˺˺
Compatible with the 201 PV Jr.
Vice and 300 & 305 Bases
˺˺
Includes six non-marring, anti-skid pads
˺˺
Three 1/4-20 holes are drilled and tapped
on the outer lip for mounting accessories
˺˺
Overall diameter:
8.5" (215.9mm)
˺˺
Height:
0.75" (19.1mm)
˺˺
Weight:
1.9 lbs. (0.9kg)
˺˺
Overall diameter:
8.5" (215.9mm)
PV312
52801955
335 MAGNETIC BASE MOUNT
Attach a PanaVise to any flat, ferrous metal surface!
˺˺
Perfect for machinery, truck beds, tool boxes...
anywhere magnets are NOT a problem.
˺˺
Compatible with the
201 PV Jr. Vice, and
300 & 305 Bases
˺˺
Magnet is slightly
recessed into
Base Mount to
avoid scratching
metal surfaces
˺˺
Magnetic power
holds up to 5 lbs.
(2.3kg)at 90°
˺˺
Overall diameter:
4.32" (2.28mm)
˺˺
Height: 0.5" (12.7mm)
˺˺
Weight: 1.0 lbs. (0.4kg)
PV335
52801960
380-PORTABLE VACUUM
VICE BASE
Create the world's most PORTABLE work holding
tool! Simply flip the lever to "activate" the rubber
pad and attach the unit to any smooth, non-porous
flat surface. Add any of the compatible Vice heads
and build a versatile, portable work station.
˺˺
Accepts all 300
series heads and
any 5/8" (15.9mm)
diameter shaft
˺˺
Pad footprint
measures
5.125" x 4.25"
(130.2mm x108mm)
˺˺
Patented single
control knob and
exclusive "split-ball"
locks head
firmly in place
˺˺
Height:
3.25" (82.5mm)
˺˺
Weight: 1.7 lbs. (0.8kg)
PV380
52802010
