SINGLE INPUT MODULE WALL PLATE
Resi-linx 'linx-Audio' now
allows you to wirelessly stream
audio from your portable
device (iPod, iPad, iTouch
etc)around your home or
business with ease, with the
new resi-linx Bluetooth wireless
technology enabled range.
˺˺
RL-BT430 Single Input Wall Plate for RL-BT100.
RLBT430
39894310
BLUEWAVE 20W RMS AMPLIFIER
Retro fit to any
in-ceiling speaker
˺˺
20 Watt RMS
Amplifier
˺˺
Built-in Bluetooth
˺˺
Up to 20m range
˺˺
Easy to install
˺˺
Connects to
any speaker
BTA1000
39894320
BLUETOOTH MUSIC RECEIVER 20M
Stream music wirelessly
from your smartphone/
tablet to any stereo/stand-
alone speaker via Bluetooth
˺˺
Connect with
your Bluetooth
or NFC-enabled
device, using the
HA100 or NFC Tag
˺˺
Connects to any
stereo supporting
3.5mm or RCA jacks
˺˺
Transmits up to
20 meters (66
feet)away, within
direct line of sight
˺˺
Bluetooth 4.1,
compatible with
all A2DP stereo
Bluetooth devices
HA100
39894365
PORTABLE BLUETOOTH RECEIVER
˺˺
Battery life up to 20
hours (fully charged)
˺˺
Internal
rechargeable battery
via USB to mini USB cable.
˺˺
Includes a 3.5mm to 3.5mm cable
and 3.5mm to R/L audio cable.
˺˺
Can be used with MP3, Smart Phones,
Bluetooth devices to connect to
speakers, AV receivers, car aux
˺˺
Sync up to 8 paired devices
˺˺
Up 10m of playback distance
˺˺
Sync up to 8 paired devices
AIRBLUE
39894380
WI-FI MUSIC RECEIVER
The Pro.2
WMR14 AirPlay
and DLNA Music
Receiver brings
your Hi-Fi System
the flexibility of
Apple AirPlay and, industry standard, DLNA.
˺˺
Connects to your existing home or office Wi-Fi
˺˺
Alternatively creates its own hot-spot, allowing
up to 10 devices to connect to it at a time
˺˺
Supports Wi-Fi 802.11b/g/n
˺˺
Apple AirPlay support for iOS devices
˺˺
DLNA/UPnP support for Windows
Media Player and Android Apps
˺˺
Digital and analogue outputs
˺˺
Supports multiple units on the same network
WMR14
39894390
6X ZONE/12CH POWER AMPLIFIER
High efficiency more than 85% (class D)amplification.
˺˺
50W x 2 @ 4Ω
output power
per zone
˺˺
4Ω /70V /100V
output selectable
˺˺
Stereo/Bridge
mono output
˺˺
Line and bus
input selectable
˺˺
12V DC trigger out
˺˺
Wired DC remote
volume for each zone
˺˺
Input level limit
MAP1270
01618945
150W 2CH POWER AMPLIFIER
The POWERPRO300 stereo power amplifier
represents the state of art design. Featuring
dual inputs with signal sensing, POWERPRO300
amplifier can be configured to turn on automatically
when music is sensed on the inputs. Input-1 will
override Input-2 whenever the signal is present, this
makes the POWERPRO300 the perfect amplifier
for a zone amplifier for multi-room distribution
system. Local sources take priority at any time.
˺˺
150 Watts RMS
per channel power
amplifier with
complete custom
installer feature set
˺˺
Bridgeable outputs
for 470 Watts RMS
total output power
˺˺
2 pairs of Stereo
RCA input:
1 pair of primary,
1 pair of priority
˺˺
1 pair of high-level
speaker input
˺˺
1 pair of Stereo
RCA output
˺˺
Automatic source
switching with
adjustable delay
timer (3-15 seconds)
˺˺
Two sets of speaker
outputs selectable
from the front panel
POWERPRO300
01618955
6-ZONE DISTRIBUTION AMPLIFIER
Distribute audio up to 18-zones
˺˺
Controlled by package keypads
or IR remote controller
MAP1200HD
01618960
VOLUME CONTROL FACE PLATE
Face plates for multi-
room volume controllers
˺˺
Interchangeable face
plates available in
Black and Silver
˺˺
Sold individually
RLMRA2B
39894226
RLMRA2S
39894225
MULTIROOM VOLUME CONTROL
Volume Control with powerful inbuilt 12W RMS
amplifier for use with Audio Distribution Module
(RL-MRA310). Powered remotely via power cable
connected to the Audio Distribution Module.
˺˺
Powered remotely
via power cable
connected to the
Audio Distribution
Module
˺˺
LCD display
for Functions /
Source Indicator
˺˺
Setting Lock and
Boost option
˺˺
Fully functioned
Remote Control
included featuring
Lock and Boost
settings
˺˺
Test Port for
system check
˺˺
Frequency Response:
20Hz ~ 20kHz
˺˺
Power Input: 24V DC
RLMRA210
39894230
MULTI ROOM AUDIO INPUT MODULE
4-Source Audio Distribution Module for
use with Amplified Volume Controls.
˺˺
Frequency Response: 20 Hz ~ 20 kHz
˺˺
Push clamp terminals for Volume
Control power cable
˺˺
IR control of source from Volume
Control via emitter output ports
˺˺
System status display (source to zone indication)
˺˺
Power Input: 24V DC 3.75A
RLMRA310
39894235
50W COMPACT BLUETOOTH AMP
resi-linx Compact
amplifier
˺˺
50 Watts RMS
per channel
˺˺
Bluetooth
connectivity
˺˺
Only requires power
and speakers
˺˺
Control your music
directly from
you Bluetooth
enabled device
RLBT600
39894295
67
AV ACCESSORIES
MULTIROOM AV DISTRIBUTION
B
MULTIROOM AUDIO
