ROTARY
PLASTIC ROTARY
SWITCH
All moulded plastic, enclosed
design with round type shaft.
Posidex indexing gives excellent
positive movement.
˺˺
Rating: 5A
˺˺
Max Voltage: 300V AC/DC
˺˺
Break-before-Make contacts
˺˺
Indexing: 30°
SP12T
SR6001
41276001
3P4T
SR6032
41276032
4P3T
SR6048
41276048
OPEN METAL
ROTARY SWITCH
˺˺
Open design, 30mm Diameter,
round 6.3mm metal shaft
˺˺
Break before make contacts
˺˺
Silver plated brass terminals
˺˺
Contact Rating: 125V 500mA
SP12T
SR6501
41276501
DP6T
SR6512
41276512
DP5T
SR6524
41276524
3P4T
SR6536
41276536
4P3T
SR6548
41276548
6P2T
SR6560
41276560
TERMINALS
SCREW & POST
HEAVY DUTY TERMINAL
Captive head, electro-tinned brass
threaded internal components and
injected moulded high quality ABS
insulation. Terminal bases have a
moulded tongue to prevent turning
˺˺
Insulation washer, 2
nuts and 2 washers
˺˺
Mounting hole: Ø16mm
˺˺
Overall height: 75mm
TP1001
43651001
TP1002
43651002
TP1004
43651004
NON-CAPTIVE BANANA
BINDING POST
4mm Banana socket, non-captive
head with insulation washer
˺˺
Mounting hole: Ø8.2mm
˺˺
Overall Diameter: 13.5mm
˺˺
Overall height: 36mm
TP1901
43651901
TP1902
43651902
CAPTIVE BANANA
BINDING POST
4mm Banana socket, captive head
type, plastic thread with double flat.
˺˺
Mounting hole: Ø8.2mm
˺˺
Diameter: 11mm
˺˺
Height: 50mm
TP1931
43651931
TP1933
43651933
TP1935
43651935
TP1932
43651932
TP1938
43651938
TP1934
43651934
GOLD PLATED
SPEAKER POST
˺˺
Side entry type with
4mm banana socket
˺˺
17mm post
˺˺
Knurled head
˺˺
Coloured ring
˺˺
Height: 42mm
˺˺
Diameter: Ø10mm
TP2814
43652814
TP2815
43652815
12MM LARGE TACTILE
SWITCH
PC mount Single
pole normally
open keyboard
switch with
metalic contacts.
˺˺
Rating:
24VDC 50mA
˺˺
Stroke: 0.2mm
˺˺
Pins 12.5mm x 5.0mm pitch
˺˺
Contact Resistance: <100m@ 150gf
˺˺
Operating Force: 100 ±30gf
˺˺
Dimensions: 4.3 x 12 x 12mm (HWD)
SP8027
41168027
KEY
MINI TUBULAR KEY SWITCH
Mini, chrome plated brass housing.
˺˺
Tubular key can be removed in
On or Off position (45° travel)
˺˺
Rated at: 240VAC 1Amp
˺˺
Size: Overall Length: 30mm
˺˺
Mounting Hole Diam.: 10.5mm
30mm
SK1001
41061001
REGULAR KEY
SWITCH ON /OFF
Zinc alloy diecast housing & cylinder
with weather proof shutter.
˺˺
5-Disc tumbler cylinder
˺˺
Double bitted flat key, can
be inserted either way
for easy operation
˺˺
3-Terminal changeover type
˺˺
Rated: 250VAC 3Amp.(45° travel)
˺˺
Dimensions: Length 50.3mm
˺˺
Mounting Hole Diam.: 19mm
SK1065
41061065
DPDT SHORT BARREL
KEY SWITCH
Bright nickel plated zinc alloy,
stainless steel facing.
˺˺
Single bitted key can be
removed in on or off positions
˺˺
6 terminal DPDT
˺˺
Rated: 250VAC 2Amp
˺˺
45° indexing
˺˺
Short barrel
SK1080
41061080
PCB MOUNT
MOMENTARY PUSH ON
PCB SWITCH
Ultra long life
SPST PCB mount
Momentary On,
designed for digital
electronic controls.
˺˺
Pins 5mmL x
5mm pitch
˺˺
Rating: 35Volts/10mA
˺˺
Travel: 0.8mm
˺˺
Dimensions: Button - 9.0 Ø
Base - 12 Ømm x 14.5mmH
SP8006
41168006
6MM SMALL TACTILE
SWITCH
PC mount Single
pole normally
open keyboard
switch with
metalic contacts.
˺˺
Rating: 24VDC 50mA
˺˺
Stroke: 0.2mm
˺˺
Pins 6.5mm x 4.5mm pitch
˺˺
Operating Force: 100 ±30gf
˺˺
Contact Resistance:
<100m @ 150gf
˺˺
Dimensions: 4.3 x 6 x 6mm (HWD)
SP8025
41168025
DPDT MINI SLIDE SWITCH
DPDT slide action switch
with solder terminals.
˺˺
Rating: 125VAC @ 0.5Amp
˺˺
Hole Centres: 28mm
˺˺
Size: 35 x 7.5 x 13mm (WHD)
SS1016
41321016
