2-WAY 100V CEILING SPEAKER
Indoor light weight
ceiling speaker ideal
for speech and music
where wide dispersion
and pronounced high
frequency response
is required.
˺˺
Coaxial woofer
& Tweeter
˺˺
Line Voltage:
100/70V
˺˺
Frequency Response:
80Hz ~ 16kHz
˺˺
>86 dB sensitivity
6"
1.5 /2.5 /5 /10W
QTC1060B
38905017
8"
0.75/1.5/3.25/7.5/15W
QTC1080
38905012
6"
1.5 /2.5 /5 /10W
QTC1060
38905016
6" 100V 10W PA SPEAKER
˺˺
2-way, dual-cone
in-ceiling
˺˺
70/100V transformer
˺˺
Metal grille and
ABS baffle
6" 1.25, 2.5, 5, 10W
T206BC
38905042
8" 1.87, 3.75, 7.5, 15W
T208BC
38905044
6W 100V QUICK CEILING MOUNT
SPEAKER
The unique
mounting method,
makes these
ceiling speakers
ideal for installers.
Retractable
springs, securely hold speaker to mounting
frame, to check or rewire simply pull down and
tilt, after servicing just push back into place!
˺˺
Screw terminals
˺˺
All Metal Construction
5.25" 1.5, 3, 6W
QCM5061
38907033
100V 5W SURFACE MOUNT
CEILING SPEAKERS
Fitted with a 100V line
multi-taped transformer
& 4-way wire protected
terminal strip with 22uF
bipolar capacitor for
line monitoring applications in EWIS systems.
˺˺
Power taps: 0.33, 0.66, 1.25, 2.5 and 5W
4" (100mm)
100Hz ~ 20kHz
C0701
39737041
8" (200mm)
75Hz ~ 15kHz
C0715
39737044
6W 100V LINE CEILING SPEAKER
Separate Type
Celling Speakers.
˺˺
Domed flush-mount
12cm dynamic
cone speaker
˺˺
Speaker protected
by hard cover
˺˺
Plug-in connectors
for quick wire
hook-up
˺˺
Two-branch type
bridging terminal
for bridging
speaker lines
CM960/CP97
39737100
5" WEATHERPROOF SPHERE PA
SPEAKER
These splash
weatherproof
loudspeakers (IP44)
are designed to be
suspended from ceiling via their 5m 6-core
connecting cable that is easy to shorten for
desired height. The cable clamp-and ceiling
cover are supplied and colour-matched the
pendant sphere. So they can effectively bring
the design of an interior space for completion.
˺˺
Input power: RMS
10W /Max 20W
˺˺
Output power: 2.5,
5, 10W /8Ω
˺˺
Speaker: 5" wide
band speaker
˺˺
Input voltage:
70 /100V
˺˺
Input Impedance:
100V (4kΩ /2kΩ /
1kΩ), 70V (2kΩ /
1kΩ /490Ω), 8Ω
5"
10W
CSR105Y
39774165
5"
20W
CSR205Y
39774170
6"
20W
CSR206Y
39774175
6"
30W
CSR306Y
39774180
30W 5" 100V CEILING SPEAKER
TOA F-Series ceiling
Speakers are ideal
for music and paging
applications such
as audio/visual,
business music or
retail sound systems.
˺˺
Special diffuser
provides wide
off-axis high
frequency response
˺˺
Ported bass-
reflex design
˺˺
Co-axial: 5"
cone driver and
dome tweeter
˺˺
Wide-dispersion:
170º conical
(1-4k Hz avg.)
˺˺
Frequency Response:
70 to 20k Hz
˺˺
Sensitivity: 90 dB
SPL (1 W, 1 m)
F2352C
39776100
12W 100V LINE SURFACE MOUNT
2-way surface mount
speaker system has
been designed as an
ideal ceiling speaker
for applications
that require high-quality audio.
˺˺
Sleek, Stylish Appearance blends
well with modern architecture
˺˺
Weather-Proof Version Available, Model H-2WP
˺˺
Minimum Reflection Design reduces
sound wave reflections
˺˺
Two-Way, Sealed Enclosure with
High-Quality Components
˺˺
1" balanced-dome tweeter, Ferrofluid cooled
H2
39776110
100V LINE PENDANT SPEAKERS
Ideal for high ceilings
and open space
environments.
˺˺
Wide dispersion
angle
˺˺
15W high power tap
provides flexibility for
music installations
˺˺
Selectable power
taps via multi-
core cable
˺˺
Includes ceiling rose
for a neat finish
˺˺
Choice of black
or white casing
˺˺
Contemporary
off-white colour
for architecturally
unobtrusive
installation
C1051
38901016
C1050
38901015
4" 2-WAY 100V CEILING SPEAKER
The QTC2040BC is a
100V ceiling speaker
with high efficiency
and vocal definition
˺˺
2-way co axial
˺˺
70v /100V
and 8 ohm
˺˺
Tappings: - 20w,
10w, 5w, 2.5w
˺˺
Flush mount
with fast fit
˺˺
Fire resistant plastic
vented enclosure
+ metal grill
QTC2040BC
38905013
30W 8" PENDANT SPEAKER
PE-304 have an
outstandingly stylish
design that is inspired
by the finest lighting
fixtures, allowing them
to harmoniously blend in
with lighting equipment.
˺˺
Rated Input: 30W
(100V /70V /8Ω)
˺˺
Speaker: 5" (12cm)
cone-type & balanced
dome tweeter
˺˺
Dimensions:
Ø186 × 251(H)mm
˺˺
Frequency Response:
70 ~ 20,000Hz
(peak –20dB)
PE304BK
39654050
PE304
39654052
6" 100V BLACK PENDANT SPEAKER
Elegant Pendant speaker
˺˺
6" Full Range Driver
˺˺
Built-in 100v/
70v transformer
˺˺
Power Taps at
3.75w, 7.5w,
15w ( 100V )
˺˺
Aluminium enclosure
& metal grille
˺˺
Security lock ring
T200B
38905035
138
SPEAKERS PA & DJ
B
CEILING PA - 100V
PUBLIC ADDRESS
